The damper can be adjusted from the top and locked into place to avoid tampering. Tate's perforated panel delivers airflow in a vertical plume and is a cost-effective airflow panel for use in contained aisles. Steel perforated panels are available with a SparkLite white powder coating or laminated with high pressure laminate, vinyl or rubber floor coverings. The perforated panels are interchangeable with laminated ConCore and All Steel panels in a stringered system.
25% open areaPerforated All-Steel constructionNon-combustible materialAvailable with top surface adjustable dampersProtected from corrosion by an epoxy paint finish| Static Pressure (in. H20) |
Air Volume (CFM) |
Air Volume with Damper Open (CFM) |
Air Volume with Damper Closed (CFM) |
|---|---|---|---|
| Laminated Perf 1250 Panels | |||
| 0.02 | 370 | 260 | 10 |
| 0.04 | 440 | 300 | 20 |
| 0.05 | 480 | 340 | 40 |
| 0.06 | 515 | 350 | 50 |
| 0.08 | 575 | 375 | 55 |
| 0.10 | 700 | 490 | 60 |
| Powder Coated Perf 1250 Penls | |||
| 0.02 | 395 | 280 | 10 |
| 0.04 | 470 | 330 | 30 |
| 0.05 | 525 | 350 | 40 |
| 0.06 | 560 | 380 | 50 |
| 0.08 | 620 | 405 | 50 |
| 0.10 | 750 | 520 | 55 |
